Terminal blocks

The screws of the detachable terminals are best handled with a 2.5 mm screwdriver.

Connector	Description
1, 2	Supply voltage (12-30 VDC) With PoE-connected door controllers, 12 or 24 VDC are delivered, which is adjustable in VAKA. Terminal 1 is positive (+).
1 - 4	Connection for readers. See reader manual for recommended cable, lengths etc.
5, 6	AUX output, potential-free relay. Used for lock control (NO / NC), door automation, local / global alarm event or gate opening. Connecting electric lock: Jumper between 1 and 5 and connect the lock to 6 and 2 (standard or fail safe function for lock is set in VAKA).
7, 8	Input for exit button Closing of the input gives an unlocking.
9, 12, 13	Not used, not to be used as connection points.
10, 14	Input door contact.
11, 14	Input bolt contact.
